Model | Temp Range（℃） | Fluctuation | Flow rate | Working Size | Depth | Dimensions（mm） |
（±℃） | (L/min) | （mm2） | （mm） | L*W*H | ||
SC-6 | RT～100.00 | 0.03 | 6 | 180x160 | 150 | 370x380x440 |
SC-6A | RT～200.0 | 0.1 | internal circulation | 180x160 | 150 | 370x380x440 |
SC-10 | RT～100.00 | 0.03 | 6 | 180x160 | 200 | 370x380x490 |
SC-10A | RT～200.0 | 0.1 | internal circulation | 180x160 | 200 | 370x380x490 |
SC-15 | RT～100.00 | 0.03 | 6 | 235x160 | 200 | 400x380x520 |
SC-15A | RT～200.0 | 0.1 | internal circulation | 235x160 | 200 | 400x380x520 |
SC-20 | RT～100.00 | 0.03 | 6 | 310x280 | 150 | 480x520x550 |
SC-20A | RT～200.0 | 0.1 | internal circulation | 310x280 | 150 | 480x520x550 |
SC-25 | RT～100.00 | 0.03 | 6 | 235x160 | 300 | 370x380x620 |
SC-25A | RT～200.00 | 0.1 | internal circulation | 235x160 | 300 | 370x380x620 |
SC-30 | RT～100.00 | 0.03 | 6 | 310x280 | 230 | 480x520x550 |
SC-30A | RT～200.0 | 0.1 | internal circulation | 310x280 | 230 | 480x520x550 |
SC-40 | RT～100.00 | 0.05 | 6 | 400x380 | 200 | 550x630x520 |
SC-40A | RT～200.0 | 0.1 | internal circulation | 400x380 | 200 | 550x630x520 |
SC-50 | RT～100.00 | 0.05 | 6 | 350x300 | 300 | 480x605x600 |
SC-50A | RT～200.0 | 0.1 | internal circulation | 350x300 | 300 | 480x605x600 |
SC-70 | RT～100.00 | 0.05 | 6 | 600x300 | 300 | 505x605x600 |
SC-70A | RT～200.0 | 0.1 | internal circulation | 600x300 | 300 | 505x605x600 |
SC-90 | RT～100.00 | 0.05 | 6 | 500x500 | 300 | 400x1100x650 |
SC-90A | RT～200.0 | 0.1 | internal circulation | 500x500 | 300 | 400x1100x650 |
